VHM
Solid carbide
TB
45

345NL TB

Intended for machining aluminium, its alloys, and other non-ferrous metals.

Protection
TB

Tools are protected against wear and tear by TB coat. Due to lack of chemical affinity for aluminium, it reduces build-up on cutting edges during the machining of its alloys, which significantly extends the life-time of materials from N group.

Application
  • P
    Steels and cast steels
  • M
    Stainless steels
  • K
    Cast iron
  • N
    Non-ferrous materials
  • S
    Super alloys
  • H
    Tempered materials
Dimensions
Index
ød1
ød2h6
d3
l1
l2
l3
apmax
R
Z - flute number
End mill shank type
M9-34B7A0-0030
3
6
2,7
57
7
17
3
walcowy
M9-34B7A0-0040
4
6
3,7
63
8
22
3
walcowy
M9-34B7A0-0050
5
6
4,7
67
10
27
3
walcowy
M9-34B7A0-0060
6
6
5,5
74
10
32
3
walcowy
M9-34B7A0-0080
8
8
7,5
90
12
46
3
walcowy
M9-34B7A0-0100
10
10
9,2
102
14
55
3
walcowy
M9-34B7A0-0120
12
12
11
117
16
64
3
walcowy
M9-34B7A0-0160
16
16
15
141
22
87
3
walcowy
